Welcome to 3DWhiffletree!
What's New
Oct. 25, 2017: Sister site "Step by Step FEM" opened. See the link at left menu.
- Perfect resources to learn Finite Element Method for begineers, yet completely covers basic mathematics of FEM theory.
- No more fake FEM learning.
- Contents being added.
Apr. 2, 2017: Updated testimonials
Mar. 20, 2016: Version 1.4.1 Now Released!
(See all updated histories here.)
Version 1.4.0 & 1.4.1 Highlights
- It's 100% free!
- What's New:
- Give users warning message when user entered material allowable which is different from calculated value.
- Now point information shows load. Also information is given in units and user-set decimal places.
- Now users can save color settings.
- Now warning message for beam length can be turned off directly from the message dialog.
- Fixed a bug for point/rod/beam size after reopening a new model.
- Minor update on Catia export.
What can you do with 3DWhiffletree?
- Design whiffletree structures with 3D graphic control
- Create, edit or modify whiffletree design without tedious calculations
- Read FEM data to display models with whiffletree structures
- Automatically define the best material to construct actual whiffletree for static test
- Create whiffletree diagrams and export diagrams to Word and Excel
- Export whiffletree structure to CATIA
Who should use this software?
- Structural engineers in aerospace industries (most common)
- Mechanical engineers and test technicians working in static test lab
- Students in mechanical and aerospace engineers, as well as civil and manufacturing engineers
